Overview:
The Runcam Split 4 is an innovative camera solution designed for FPV drones, offering both high-definition recording and an analogue FPV output signal. With its 13MP Sony sensor and a 140-degree field of view, the camera captures stunning 4K footage at 30fps, as well as 2.7K at 60fps and 1080P at 60fps for versatile recording options.
The camera boasts a low latency of approximately 55ms, ensuring a responsive flight experience. It supports a wide voltage range from 5V to 20V and features UART control for easy integration with flight controllers. The Split 4's compact design includes a 14mm lens module and a 29mm PCB, with 25.5mm mounting holes for straightforward installation on a variety of drone frames.
Designed with durability and performance in mind, the Runcam Split 4 also includes power-off protection for video files, safeguarding your recordings even in the event of unexpected power interruptions.
Runcam Split 4 Specifications:
- Model: Split 4
- Image Sensor: SONY 13MP
- Field of View(FOV): 140°
- Video Resolution: 4K@30fps/2.7K@60fps/2.7K@50fps/1080P@60fps
- Video File Format: MP4
- TV Mode: NTSC (720*480)/PAL (720*576) Switchable
- Interface: UART
- Max Micro SD Card Supported: Max. 128GB
- SAMSUNG 128GB U3 recommended (2.7K60/2.7K50/1080P120 requires U3 or above; other solutions require U1 or above)
- Please make sure that the file format of the SD card is exfat, otherwise, it will easily cause errors.
- Power Input: DC 5-20V (Non-direct power supply from battery,Powered direcly with battery will generate surges - and burn the camera.)
- Lens Module Size: 14*14mm
- Mounting Hole Distance: 25.5*25.5mm
- PCB Size: 29*29mm
- Working Current: MAX 450mA @5V
- Weight: 10.2g
Includes:
1x Runcam Split 4
Accessories
