Overview:
The SKYRC D200 neo / D200neo charger is a dual input, dual output charger that can charge up to 6S LiPo/LiHV/LiFe/LiIon, 15S NiMH/NiCd and 12S Pb batteries with a maximum power of 800W on DC input and 200W on AC input. It has a user-friendly interface with a color LCD display and a scroll button control. It also supports parallel charging, external discharging, battery analyzing, DC power supply and USB Type-C PD/QC3.0 fast charging.
The SKYRC D200 neo charger is compatible with the SkyCharger app and the Charger Master software, which allow you to control and monitor the charging process via Bluetooth or USB connection. You can also use the optional PCH-150 Power & Charging Hub to connect multiple devices and charge them simultaneously.
The SKYRC D200neo charger is designed with safety and reliability in mind. It has a smart ventilation fan, a precision aluminum unibody enclosure, and multiple protection features such as short circuit, overload, reverse polarity, over temperature and over voltage.
Specifications:
- Model: D200 Neo / D200neo
- DC Input Voltage: 10-30V
- AC Input Voltage: 100-240V
- Maximum Charging Output: (AC-200W) (DC-800W)
- Supported Battery Types: 1-6 Cells (LiPo/LiHV/LiFe/LiIon) / 4-15 Cells (NiMH/NiCd) / 3S/6S/12S (Pb)
- Charge Current: 0.1-20.0A (Parallel 20.0-35.0A)
- Discharge Current: 0.1-2.0A (External 0.1-40.0A2)
- Balance Current: 1.5A MAX
- USB Type-C Output: QC3.0: 5V⎓3A, 9V⎓2A, 12V⎓1.5A / PD: 5V⎓3A, 9V⎓2.2A, 12V⎓1.67A
- Case Size: 11611079mm
- Weight: 602g
Included:
- SkyRC D200 neo AC Charger
- UK AC Cable
IMPORTANT: Never charge batteries unattended! Constant supervision is required as batteries can be dangerous when mishandled. We recommend charging your batteries inside a protective charging bag.
