T-Motor AT2317 880KV Fixed Wing Motor

Overview:

The T-Motor AT2317 is a motor designed for Fixed Wing models. The AT series design features increased cooling and efficiency.The AT series provides upgraded quality including arc magnets which increase motor performance by 5%.

This version comes with a long shaft and is 880KV.

Specifications:

- KV: 880KV Long Shaft
- Configuration: 12N14P
- Shaft Diameter: 4mm
- AWG: 20#
- Cable length: 100mm
- Internal Resistance: 82mΩ
- Motor Dimensions (Dia.*Len): Φ28.8x52mm
- Weight with wires(g):79g
- ldle current@10v(A): 0.9A
- No.of Cells(Lipo): 2-4S
- Peak Current: 25A
- Prop recommendation 10x4.7 (4S) / 11x5.5 (4S) / 12x6 (3S) / 13x8 (3S)

Includes:

- 1x T-Motor AT2317 880KV Long Shaft Fixed Wing Motor
- Mounting Screws, prop adapter & Lock Nut
