TrueRC X-AIR 1.3GHz Crosshair Antenna (RHCP)

The TrueRC X-AIR 1.3 is our latest redesign of the crosshair antenna.
Manufacturer: TrueRC
Availability: In stock
£76.35 inc VAT
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview:
The new X-AIR 1.3 is our latest redesign of the crosshair antenna. It put an end to the only downside of this type of antenna: their size. Almost 1/4 of the footprint of the original,  same wide coverage and high axial ratio make it perfect for far off venture without antenna aiming adjustment. A 1/4-20 mounting point in the back, make that feather weight super easy to attach to your ground station.

** Current stock is black not white **

Specifications:

- Frequency: 1.3GHz
- Gain: 10 dBic
- Polarization: RHCP
- Radiation efficiency : 98%
- Beam-width*: 120deg
- Beam-width @-3dB**: 68deg
- Connector: SMA male
- Dimension: 152mm x 152mm x 30mm
- Mounting: Standard 1/4-20 flush thread
- Weight: 135g
- Included 7cm flexible low loss extension.

Package Contents:
- 1x TrueRC X-Air 1.3GHz Crosshair (RHCP)

- 1x Low loss semi flexible extension
